True Refrigeration Undercounter Foodservice Refrigerator, 1 Glass Swing Door - Right-Hinged - TUC-24G-HC-FGD01-RH

Name: True Refrigeration Undercounter Foodservice Refrigerator, 1 Glass Swing Door - Right-Hinged - TUC-24G-HC-FGD01-RH
Brand: True Refrigeration
SKU: TUC-24G-HC-FGD01-RH
Price: 4222.30 AUD
Availability: InStock

Special Price $4,222.30 $3,838.45 Regular Price $5,483.50 $4,985.00 SAVE $1,261.21 SAVE $1,146.55

True Refrigeration See all True Refrigeration products

True Refrigeration Undercounter Foodservice Refrigerator, 1 Glass Swing Door - Right-Hinged - TUC-24G-HC-FGD01-RH is a commercial back bar fridge supplied under the Bromic manufacturer range. Model: TUC-24G-HC-FGD01-RH. Key operating details include temperature range 0.5 : 3.3°C, R290 refrigerant, 158 L gross volume.

The specifications below are sourced from the official Australian True Refrigeration product documentation. Confirm site access, electrical requirements and clearances before installation.

Dimensions

External Width (mm)	610
External Depth (mm)	627
External Height (mm)	802
Exclusions	Depth does not include 26mm for rear bumpers and 42mm for door handle.
Net Volume (Litres)	94
Gross Volume (Litres)	158
Display Area (m 2 )	0.25
Supplied Shelves	2
Shelf Size (L x D mm)	One 508 x 352 + One 508 x 273
Internal Net Height (mm)	600
Unpackaged Weight (kg)	64
Packaged Weight (kg)	75
Packaged Dimensions (W x D x H mm)	788 x 762 x 1016
Supplied with	Built-in recessed castors (7mm clearance)

Build

Door Description	1 Full Glass Swing Door
Door Opening	Right (standard) or Left
Exterior Construction	Stainless steel front & countertop, aluminium sides & rear
Interior Construction	Clear coated aluminium, stainless steel base
Air Intake Position	Front
Ventilation Position	Front
Clearance Required	Zero back and sides
Cord Length (Meters)	2.13
Internal Lighting	LED
Standard w/ Locks	Standard

Technical

Temperature Range	0.5 : 3.3°C
Refrigerant	R290
Voltage/Frequency/Phase	220-240V/50-60Hz/1
Amps	1
Watts	230
Temperature Class	M1
Operating Statement	Tested at 25°C, 60% RH, per ‘Refrigerators with a Direct Sales Function’ for perishable food merchandising.
Test Standard	EN 23953
EEC	A
Energy Efficiency Index	9.3
Defrost Type	Auto
Energy Consumption (kWh/24h)	1.33
Energy Consumption (kWh/Annum)	489

Official Product Specification Sheet

View or download the True Refrigeration PDF for model TUC-24G-HC-FGD01-RH.

View Specification PDF

SKU	TUC-24G-HC-FGD01-RH
Dimensions	610 × 627 × 802 mm (W × D × H)
Power	220-240V/50-60Hz/1, 1 A
Capacity	158 L gross
Warranty	5 Years Bromic Extra Care Warranty - Labour and Parts
